The challenge was based on Oracle's time of 71.5 seconds on query five of the TPC-D benchmark. Administered by the Transaction Processing Performance Council, the TPC-D benchmark was designed to test the efficiency and speed of very large databases in "an ad hoc business environment where users submitted more or less random queries against a data warehouse." The challenge seemed straightforward enough: build a terabyte-scale database that includes customers, suppliers, orders, parts, and revenue over time and geography, and then answer the basic business question of "how much of last year's revenue was shipped nationally vs. internationally."

Not that Oracle's query five results were causing the Microsoft SQL group to lose sleep; while 71.5 seconds was a decent enough mark, it certainly wasn't ground-breaking news. Rather, it was the fact that Oracle CEO Larry Ellison had turned TPC-D into such a solid public relations coup. For in truth, although the Oracle Challenge sounded simple, it was anything but straightforward.

"On its face the Oracle Challenge seemed credible and fair," says Doug Leland, SQL Server group product manager for Microsoft. "But it was a loaded deck. To put Oracle's offer in any kind of perspective, you had to understand the minutia of benchmark deadlines and database creation. All in all, it was a very clever ploy on their part."

At issue was a new approach to database architecture called "materialized views" that was making it possible for companies to report TPC-D query execution times of less than one second, an incredible improvement compared with the 1,000 seconds that was typical in April 1998. But materialized views had fundamentally altered the nature of the test and, as a result, the value of the TPC-D benchmark for evaluating database technologies had become very unclear. So unclear, in fact, that in February the General Council of the Transaction Processing Performance Council voted to recommend that TPC-D be abolished and split into two separate benchmarks.

Beyond the question of materialized views, there was an even more important issue at stake, says Leland, and that was the value of TPC-D as a measure of the business benefits of database technologies. Oracle's execution times for TPC-D were achieved with a solution that cost over $10 million, a cost far beyond the means of many companies that would benefit from terabyte-level data warehouses and decision support databases.

"The Oracle Challenge wasn't terribly relevant to customers," said Leland. "It was based on a single query in a larger benchmark, with terms and conditions that don't reflect real business conditions, and it required an extremely expensive system. We believe that customer benefits derive from a broader picture that takes into consideration such issues as affordability and return on investment."

The OLAP Approach

This month, as part of the premiere event of the "getting Results" Web cast series, Microsoft released its response time to the same query issued in the Challenge, announcing that it had achieved an execution time of 1.075 seconds on query five, significantly faster than Oracle's original mark and on par with Oracle's recent result of 0.7 seconds. Microsoft's results were achieved using Microsoft SQL Server 7.0 Enterprise Edition for a total cost of less than $600,000.

"Our solution not only matches Oracle's performance, but it does so at about one-sixteenth the price," says Leland. "It demonstrates that Microsoft offers powerful data warehousing and business intelligence solutions at a cost of ownership that is in line with real-world business realities. That's the core of our approach: to provide business solutions that drive down the cost of ownership and maximize return."

The Microsoft solution, developed jointly with Hewlett-Packard and using Hewlett-Packard hardware, is based on Microsoft's OLAP (on-line analytical processing) technologies. An integrated component of SQL Server 7.0, OLAP is an extremely flexible, high-performance approach to accessing, viewing and analyzing data.

OLAP technology uses a multidimensional approach allowing data to be ordered into descriptive categories called dimensions (such as time, geography, product, channel, and organization), and quantitative values called measures (including dollar sales, unit sales, inventory, headcount, income, and expenses). Dimensions are then organized into hierarchies: time, for example, can be broken down in years, quarters, months and days.

The OLAP data model makes it simple for users to formulate complex queries, arrange data, move from summary to detailed data, and filter data into meaningful subsets. It offers a natural, intuitive navigational method that allows end users to view and understand the information in their data warehouses more easily and more effectively, helping organizations reap the greatest value from their data.

OLAP, along with data transformation and meta data management, are just a few of the key data warehousing technologies integrated into SQL Server 7.0 as standard components. They are an important part of the Microsoft Data Warehousing Framework, a set of open interfaces and specifications designed to enable third-parties to develop tightly integrated solutions that address the broadest range of real-world business issues, while reducing the cost of acquiring, deploying, and managing large-scale business intelligence solutions.

Putting the "Ad-Hocness" Back in TPC-D

When Microsoft and Hewlett-Packard sat down together to address the Challenge, they knew that Oracle had heavily optimized for TPC-D through the use of materialized views, and the benchmark results were not very meaningful for understanding ad hoc query performance. This led to rapid escalation in TPC-D query performance, causing the Transaction Processing Performance Council to seriously consider drastic changes to TPC-D.

Materialized views are, in fact, a useful technology for some types of database queries. With materialized views, databases are optimized so that the results from specific queries can be computed in advance, saved, and then returned at incredible speeds. Materialized views work by pre-aggregating data for the query to be answered. This moves most of the work that used to be done at the execution of a query into the database design and load phase. As a result, when a query is sent to the database, the answer has already been calculated by the materialized view, rendering nearly instantaneous results. One significant downside to this technology is that queries that update the materialized view's underlying data take longer because they have to update both the base tables and the materialized view itself.

According to the March issue of the Transaction Processing Performance Council's newsletter TPC Benchmark Status, "[Material views are] very useful when . . . very knowledgeable users like database administrators know the queries and the domain well in advance, can create auxiliary structures like aggregated columns, and can optimize their databases to run these queries. . . . The problem is that TPC-D was intended to represent an ad hoc environment in which queries are submitted on a random basis and are not known in advance."

In an attempt to solve confusion over materialized views and TPC-D, the Transaction Processing Performance Council has proposed that TPC-D be replaced by two new benchmarks, TPC-R and TPC-H. TPC-R will allow for continued use of materialized views. According to the TPC Benchmark Status, TPC-H "restores the 'ad hocness' of the original benchmark workload" of TPC-D.

Rather than try to match a result in a benchmark test that was already in dispute, Microsoft and Hewlett-Packard chose to craft a solution that would more closely match actual business conditions, including the need to get maximum value from any enterprise solution. They also wanted to develop a solution that met the original intention of TPC-D.

"There was no merit in responding to the aspect of the challenge that was nothing more than a marketing stunt," explains Microsoft's Douglas Leland. "Instead, what we found interesting was the opportunity that the challenge raised for us to use our technology in a way that focuses on what customers really need, which is affordable, scalable, and powerful solutions that are flexible enough to answer a wide range of business needs and issues."

The joint Microsoft-HP project used SQL Server 7.0 Enterprise Edition, SQL Server OLAP Services, and HP NetServer LXr8000 system with four 450MHz Pentium II Xeon processors, and 4 GB DRAM. Nine HP NetRAID-3Si disk array controller cards were used, attached to 560 disk drives. All told, the entire hardware setup cost $512,899.

To test the system, 21 runs were executed. Times ranged from a high of 1.532 seconds to a low of 0.062. The mean result was 1.075 seconds. "Our joint test results prove that large-scale databases can be created, loaded, indexed, and deployed with industry standard technology at a low cost," says Michael Mahon, who manages the Software and System Development Lab at Hewlett Packard. "We have accomplished a ten-fold increase in the size of our databases without added expense or development time. We are committed to continuing our joint efforts and passing our expertise along to our enterprise customers."

"The old school of thought was that data warehousing had to be difficult and expensive to be useful," adds Microsoft's Doug Leland. "What we've demonstrated very clearly here is that the innovations of the Microsoft business intelligence platform make it possible to accomplish the same business tasks with equivalent performance to Oracle for a fraction of the price. That shows tremendous customer value."
